DUAL FIBER 8CH C29-C36 DWDM OADM WEST AND EAST

+ Top quality

This custom device is designed by Broadstick drop and add wavelength are from 29 to C36(1554.13nm~1548.51nm) , (We can support customize other waves), and west to east wavelength support :1270nm to 1547nm / 1553nm to 1620nm; in accordance with the ITU-T G.694.1 100GHZ grid, it maximizes the capacity of the C-band range.

SKU: BSWD8-C29-C36WE Category: Tag:
Download PDF

This custom device is designed by Broadstick drop and add wavelength are from 29 to C36(1554.13nm~1548.51nm) , (We can support customize other waves), and west to east wavelength support :1270nm to 1547nm / 1553nm to 1620nm; in accordance with the ITU-T G.694.1 100GHZ grid, it maximizes the capacity of the C-band range.

The 8ch DWDM OADM port is totally passive DWDM device, it support drop 8 channels and add 8 channels business in two fibers. The loss of the waves to west or east is <2.7dB, line loss of west to east (or east to west) < 5.4dB.
